    Home > Jindex PU leather 6-layer cutting robot > Shoe bag leather
    0
    CNC Leather Cutting Machine JD-AS-L Series
    Type:
    Shoe bag leather
    Model:
    JD-AS-1410L、JD-AS-1813L、JD-AS-2516L
    Intro:
    Jindex CNC single cutting bed in the operation is very flexible and diverse, can be targeted at a variety of materials, to achieve a composite of multiple processes as one of the operation, such as cutting, marking, punching, drawing, and even personalized cutting in one go. It reduces the operation
    Contacts:
    18923737801(wechat)Click there to chat with me.
    Product introduction Return to the list

    功能特點


    ◇  Electrical oscillating knife cutting head, strong strength, high vibration frequency, up to 22,000 times per minute;



    ◇  High-resolution short-focus direct projection, 1:1 pattern output for clearer and more intuitive workflow.


    ◇  The independent anti-shock design projection frame avoids the influence of the machine on the projection during the production process, making the projection more stable.


    ◇  Personalized interactive work function, making typesetting, cutting and receiving at the same time, maximizing equipment efficiency.

    ◇  The highly integrated multi-function head can simultaneously cut, punch, draw and mark.


    ◇  The self-developed automatic typesetting cutting system maximizes the need for automatic typesetting and cutting of leather and PU, and improves the utilization of leather materials efficiently, while eliminating the worries of software upgrades.


    ◇  Support international DXF, HPGL format, avoid compatibility problems between different software, and make the workflow more simplified.


    CNC Leather Cutting Machine JD-AS-L Series Technical Parameters Standard Table

    Technical Parameters/Model

    JD-AS-1410L

    JD-AS-1813L

    JD-AS-2516L

    Operating Characteristic

    1400mm*1000mm

    1800mm*1300mm

    2500mm*1600mm

    Cutting Speed

    800mm/s-1200mm/s

    Cutting Thickness

    0.5-6mm

    Cutting Material

    Leather, artificial leather, cardboard, rubber sheet, gray board, composite material, gasket, white cardboard

    Tool

    Rotating the cutter head, oscillating head, punching

    Drive Motor

    Servo Motor

    Available Pen Type/Number

    Ordinary pen, oil pen, ball pen, silver pen / 8 groups of different strokes, half knife, knife set full

    Way for Fixing Material

    Vacuum adsorption

    Repeat Accuracy

    ≦0.05mm

    Transmission Interface

    Ethernet port

    Command System

    HP-GL & GP-GL

    Transmission Material

    Linear guide, imported synchronous belt

    Voltage and Power

    AC 220V 380V ± 10%, 50HZ; Total Power 6kw;  Fuse Size 6A

    Oscillating Knife Head

    Oscillation Knife Head motor 22000 rpm,Electric and pneumatic head optional
